Dimension(L*W*H)(mm)

6500*2500*3800

Model

YuChai 4105/4108 Supercharged

Wheelbase(mm)

2250

Type

Turbocharged

Wheel track(mm)

2250

Rated(kw)

75/85

Min. Ground Clearance(mm)

400mm

Rated speed(r/min)

2400

Min. turning radius(mm)

4200

Number of cylinders - bore

4-105/4-108

Performance Parameters

transmission system

System pressure(Mpa)

28

Transmission

Fixed-axis powershift

Overall weight(kg)

9500

Number of gears

Front 4 and back 4

Max. speed(km/h)

38

Torque converter

YJ300

Max. climbing capacity(°)

35

Excavation parameters

Axle

Max. digging depth(mm)

4000/5300

Type

100 steering drive axle

Excavation unloading height(mm)

3800/4450

Tires

Max. digging radius(mm)

5400/6500

Specification

16.9-28-14

Max. lifting height(mm)

5480/6100

Travel brake

Air top oil caliper disc brake

Hopper capacity(m³)

0.3

Parking brake

Handbrake

Excavator slewing angle(°)

190

Loading parameters

Oil volume

Max. unloading height(mm)

2500

Fuel Tank(L)

Max. unloading distance(mm)

800

Loading bucket capacity(mm)

1.2

Rated loading capacity (KG)

2500

Digging force (KN)

38

Other

Drive type

Four-wheel drive

Variable speed form

Hydraulic variable speed

Manipulation System

Electromagnetic hydraulic pilot control
