● Category:
● Brand Name: Backhoe Loader
● Dimension (mm): 6100×2217×3764
● Operating Weight (kg): 8250
● Origin: China
| Transport Dimension | L*W*H (mm) | 6100×2217×3764 |
| Overall Operating Weight | 8250 KG | |
| Wheel base | 2264mm | |
| Min. Ground Clearance | 300mm | |
| Bucket Capacity | 1.0m3 | |
| Breakout Force | 38KN | |
| Loading Lifting Capacity | 2500KG | |
| Bucket Dumping Height | 2742mm | |
| Bucket Dumping Distance | 1062mm | |
| Backhoe Capacity | 0.3 m3 | |
| Max. Digging Depth | 4082mm | |
| Swing Angle of Excavator Grab | 190o | |
| Max. Pulling Force | 39KN | |
| Engine | Model | Yuchai YC4A105Z-T20/ CUMMINS 4BTA3.9-C100 |
| Type |
In Line Direct injection Four-Stroke and Injection Combustion Chamber | |
| Cylinder-Inside Diameter*Stroke | 4-110×120 | |
| Rated Power | 74KW/100HP | |
| Rated Speed | 2400r/min | |
| Min. Fuel Consumption | ≤216g/km.h | |
| Max.Torque | ≥261.7N.M/1800r/min | |
| Displacement | 4.4L | |
| Steering System |
Model of Steering Device | BZZ5-250 |
| Steering Angle | ±36 o | |
| Min. turning radius | 6581mm | |
| Pressure of the system | 12Mpa | |
| Axle | Manufacturer | Feicheng Axle Factory |
| Final Reducer | Single Stage Final Reducer | |
| Rated Loader of Axle | 8/18.5t | |
| Transmission System | ||
| Torque Converter | Model | YJ280 |
| Type | Single-stage Three Elements | |
| Max. Efficiency | 84.4% | |
| Inlet Pressure | 0.4Mpa-0.55 Mpa | |
| Outlet Pressure | 1.2Mpa-1.5 Mpa | |
| Cooling Method | Oil-cooling Pressure Circulation | |
| Gearbox | Type | Fixed Shaft Power Transmission |
| Oil Pressure of Clutch | 1373Kpa-1569 Kpa | |
| Gears | Two Gears Ahead, Two Gears Astern | |
| Max.Speed | 22Km/h | |
| Tyre | Model | 14-17.5/19.5L-24 |
| Pressure of Front wheel | 0.22 Mpa | |
| Pressure of Back Wheel | 0.22 Mpa | |
| Brake System | Service Brake | Air Over Oil Caliper Brake |
| External Type | ||
| Self-regulation | ||
| Self-balance | ||
| Emergency Brake | Operation Power Implementing brake | |
| Manual Operation Power Terminating Brake | ||
| Hydraulic System | Digging Power of Excavator Grab | 46.5KN |
| Digging Power of Dipper | 31KN | |
| Bucket Lifting Time | 6.8S | |
| Bucket Lowering Time | 3.1S | |
| Bucket Discharge Time | 2.0S | |
