● Category:
● Brand Name: Forklift
● Dimension (mm): 4200×1800×2450mm(fork not included)
● Operating Weight (kg): 4500
● Origin: China
| Lifting weight | 3,500kg |
| Machine weight | 4,500kg |
| Fork length | 1,220mm |
| Maximum grade ability | 35° |
| Maximum lifting height | 3,000mm |
| Overall dimension (L*W*H) | 4200×1800×2450mm(fork not included) |
| Minimum turning radius | 3,500mm |
| Model | Yunnei 490 turbocharged 55kW |
| Type | In-line, water cooling, four-stroke |
| Rated power | 55kw |
| Torque converter | 265 high and low speed |
| Gearbox model | Power shift |
| Gear | 2 forward, 2 reverse |
| Maximum speed | 30km/h |
| Model | hub reduction axle |
| Service brake | oil brake/air over hydraulic disc brake on 4 wheels |
| Parking brake | manual parking brake |
| Type specification | 20.5/70-16 |
| Front tyre pressure | 0.4Mpa |
| Rear tyre pressure | 0.35Mpa |
