● Category:
● Brand Name: Forklift
● Dimension (mm): 2299*1070*2140
● Operating Weight (kg): 2890
● Origin: China
| No. | Specifications | Unit | CPD18 | |||||||
| 1 | Characteristics | Power | battery | |||||||
| 2 | Capacity | kg | 1800 | |||||||
| 3 | Center of load | mm | 500 | |||||||
| 4 | Lifting height | mm | 3000 | |||||||
| 5 | Free lifting height | mm | 145 | |||||||
| 6 | Forks L×W×H | mm | 1070×122×40 | |||||||
| 7 | Mast tilt angle Forward/Backward | . | 6/12 | |||||||
| 8 | Min.turning radius | mm | 2090 | |||||||
| 9 | Min. right angle stacking width | mm | 3760 | |||||||
| 10 | Min. right angle Aisle width | mm | 2040 | |||||||
| 11 | Min.ground clearance | mm | 110 | |||||||
| 12 | Overhead guard height | mm | 2150 | |||||||
| 13 | Height from seat to overhead guard | mm | 1005 | |||||||
| 14 | Front overhang | mm | 470 | |||||||
| 15 | Perf | Max.traveling speed(loaded) | km/h | 13 | ||||||
| 16 | Max.lifting speed(loaded) | mm/s | 280 | 300 | ||||||
| 17 | Gradeability | % | 15 | |||||||
| 18 | Dimensions | Overall length (without fork) | mm | 2310 | ||||||
| 19 | Overall width | mm | 1150 | |||||||
| 20 | Mast extended height(with bracket) | mm | 4030 | |||||||
| 21 | Mast lowered height | mm | 1990 | |||||||
| 22 | Chassis | Tire | Front | 7.00-12-12PR | ||||||
| 23 | Front | 7.00-12-12PR | ||||||||
| Rear | 18×7-8-14PR | |||||||||
| 25 | Wheelbase | mm | 1450 | |||||||
| 26 | Tread width | Front/Rear | mm | 960/950 | ||||||
| 27 | Curb weight | None-load | kg | 3950 | ||||||
| 28 | Powertrain | Battery | Voltage/Capacity | V/Ah | 48/630 | |||||
| 29 | Motor | Traveling | KW | 11 | ||||||
| 30 | Lifting | KW | 10 | 14 | ||||||
| 31 | Controller | CURTIS | ||||||||
| 32 | Control type | 50%AC | 100%AC | |||||||
| 33 | Working pressure | Mpa | 17.5 | |||||||
