Specifications

Unit

FD35Z

1

Features

Power type

-

Diesel

2

Rated load

kg

3500

3

Load center

mm

500

4

Lifting Height

mm

3000

5

Free lifting height

mm

145

6

Fork size

LxWxT

mm

1070X125X45

7

Mast Tilt Angle

Front/Read

°

6/12

8

Min. Turning Radius

mm

2600

9

Min. Stacking Right Angle Channel Width

mm

4550

10

Min. Ground Clearance

Mast

mm

120

11

Overhear Guard Height

mm

2170

12

Front Overhang

mm

480

13

Rear Overhang

mm

545

14

Performances

Max. Travelling Speed

loaded

Km/h

20

15

Max. Lifting Speed

loaded/empty

mm/s

470/520

16

Max. Traction Force

loaded

KN

18

17

Max. Climbing Ability

°

20

18

Dimension

Overall Length

without fork

mm

2825

19

Overall Width

mm

1230

20

Mast Lowered Height

mm

2095

21

Mast Extended Height

mm

4265

22

Chassis

Tyre

Front

-

28X9-15-12PR

23

Rear

-

6.50-10-10PR

24

Wheel Base

mm

1800

25

Wheel Thread

Front/Rear

mm

1000/970

26

Weight(without load)

kg

4450

27

Powertrain

Battery

V/Ah

12/90

28

Engine

Model

-

C490BPG

29

Rated Power

KW/r.p.m

39/2650

30

Rated Torque

N.m/r.p.m

157/1980

31

No. of cylinder

-

4

32

Bore x Stroke

mm

90 x 105

33

Displacement

L

2.67

34

Fuel Tank Capacity

L

70

35

Transmission/Shift

-

1/1 Automatic transmission

36

Operation Pressure

MPa

17.5
