Rated Load Capacity

Q(kg)

2000

Load Centre

C(mm)

500

Lift Height

H3(mm)

3000

Free Lift

H2(mm)

100

Fork Size (L×W×T)

L/W/T(mm)

1070X120X40

F/B(α°/β°)

Deg

6°/6°

Length (To Fork Face)

L1(mm)

2075

Width

B1(mm)

1140

Mast Lowered Height

H1(mm)

2085

Mast Extended Height (With Backrest)

H4(mm)

4070

Overhead Guard Height

H5(mm)

2080

Turning Radius

Wa(mm)

1725

Fork Overhang (Wheel Center to Fork Face)

X(mm)

412

Front Tread

B2(mm)

942

Rear Tread

B3(mm)

175

Ground Clearance

H6(mm)

90

Wheelbase

Y(mm)

1538

Fork Spread (Min/Max)

mm

200/1000

Working Aisle Width With Pallet (1000×1200,1200 Lengthways)

Ast(mm)

3410

Working Aisle Width With Pallet (800×1200,800 Lengthways)

Ast(mm)

3530

Travel Speed (Full Load)

km/h

13

Travel Speed (No Load)

km/h

14

Lifting Speed (Full Load)

mm/s

250

Lifting Speed (No Load)

mm/s

400

Max.Gradeability (Full Load)

%

18

Max.Gradeability (No Load)

%

20

Total Weight (Contains the battery)

kg

3345

Tyre (Front x 2)

200/50-10

Tyre (Rear x 2)

15X4.5-8

Diver Motor

kw

4X2

Pump Motor

kw

11

Battery (Standard)

V/Ah

48/625

Controller Type

AC

Operating Pressure

Mpa

14.5
