Product classification
Product classification
● Category:
● Brand Name: Forklift
● Dimension (mm): 2570*1175*1990(without fork)
● Operating Weight (kg): 3750
● Origin: CHINA
| FD25 LPG GASOLINE FORKLIFT TRUCK SPECIFICATIONS | ||||||||
| No. | Specifications | Unit | FD25 | |||||
| 1 | 1 | Characteristics | Power | LPG GASOLINE | ||||
| 2 | 2 | Rated Capacity | kg | 2500 | ||||
| 3 | 3 | Center of load | mm | 500 | ||||
| 4 | 4 | Lifting height | mm | 3000 | ||||
| 5 | 5 | Free lifting height | mm | 135 | ||||
| 6 | 6 | Forks L×W×H | mm | 1070x122x40 | ||||
| 7 | 7 | Tilt Forward/Backward | . | 6/12 | ||||
| 8 | 8 | Min.turning radius | mm | 2240 | ||||
| 9 | 9 | Min.ground clearance(Mast) | mm | 110 | ||||
| 10 | 10 | Overhead guard height | mm | 2120 | ||||
| 11 | 11 | Height from seat to overhead guard | mm | 943 | ||||
| 12 | 12 | Front overhang | mm | 473 | ||||
| 13 | 13 | Perf | Max.traveling speed(loaded) | km/h | 19 | |||
| 14 | 14 | Max.lifting speed(loaded/empty) | mm/s | 470/510 | ||||
| 15 | 15 | Drawbar pull/Gradeability | kN/% | 17/20 | ||||
| 16 | 16 | Dimensions | Overall length (without fork) | mm | 2570 | |||
| 17 | 17 | Overall width | mm | 1175 | ||||
| 18 | 18 | Mast lowered height | mm | 1990 | ||||
| 19 | 19 | Mast extended height | mm | 4000 | ||||
| 20 | 20 | Chassis | Tire | Front | 7.00-12-12PR | |||
| 21 | 21 | Rear | 6.00-9-10PR | |||||
| 22 | 22 | Wheelbase | mm | 1600 | ||||
| 23 | 23 | Tread width | Front/Rear | mm | 970/970 | |||
| 24 | 24 | Curb weight | None-load | kg | 3750 | |||
| 25 | 25 | Powertrain | Battery | Voltage/Capacity | V/Ah | 12/90 | ||
| 26 | 26 | Engine | Model | original japan nissan k25 engine | ||||
| 27 | 27 | Rated power | kw/r.p.m | 37.4/2300 | ||||
| 28 | 28 | Rated torque | Nm/r.p.m | 176.5/1600 | ||||
| 29 | 29 | Cylinder amount | 4 | |||||
| 30 | 30 | Bore×Stroke | mm | 89×100 | ||||
| 31 | 31 | Displacement | 2.488 | |||||
| 32 | 32 | Fuel tank | L | 60 | ||||
| 33 | 33 | Transmission | 1/1 automatic transmission | |||||
| 34 | 34 | Working pressure | MPa | 17.5 | ||||
