● Category:
● Brand Name: Cargo Truck
● Dimension (mm): 5995×2210×2670
● Operating Weight (kg): 3300
● Origin: China
| Whole vehicle main dimensions |
Overall dimensions (LxWxH)mm | 5995×2210×2670 | |
| Dimensions of the cargo body (LxWxH)mm | 4170×1910×500 | ||
| Driving type | Rear-wheel drive | ||
| Wheel base (mm) | 3360 | ||
| Wheel track (front/rear) (mm) | 1540/1590 | ||
| Min. ground clearance (mm) | 210 | ||
| Weight data | Curb weight (kg) | 3300 | |
| Rated payload(kg) | 5000 | ||
| Persons in cab (persons) | 2 | ||
| Gross vehicle weight(kg) | 8430 | ||
| Whole vehicle main performance | Max. speed(km/h) | 100 | |
| Max. slope of climb(%) | 30 | ||
| Min. turning radius(m) | 7 | ||
| Engine | Model | YC4FA120-33 | |
| Type | diesel | ||
| Displacement(L) | 2.982L | ||
| Rated power(KW) | 88 | ||
| Max torque (N.m/rpm) | 345N.m/1800~2200r/min | ||
| Steering gear | power steering | ||
| Brake system | Service brake | air brake | |
| Parking brake | spring actuated and air cut-off parking brake | ||
| Auxiliary brake | exhaust brake | ||
| Tyre size | 8.25R16LT | ||
| Electric device | Rated voltage (V) | 24 | |
| Battery | 6-QW-100MF-01 | ||
| Functional Configuration | |||
| Heating system | × | ||
| Adjustable steering wheel | √ | ||
| Power steering | √ | ||
| Pre-heating | √ | ||
| Air-condition | √ | ||
| Cltuch booster | √ | ||
| Electronic control window | × | ||
| Disc brake | × | ||
| Wabco ABS | × | ||
| √ : Standard Equipment ○: Optional ×:Not develop | |||
