● Category:
● Brand Name: Concrete Mixer Truck
● Dimension (mm): 9000x2500x3945
● Operating Weight (kg): 13110
● Origin: China
| Sinotruk HOWO 6x4 Concrete Mixer Truck | |
| Chassis Model |
ZZ1257N3641W (Left/ Right Hand Driving Type Optional) |
| Engine |
Model: WD615.69, Euro 2, 371 HP 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 9.726 L |
| Clutch |
Single-plate dry diaphragm spring clutch,diameter430mm,hydraulically operating with air assistance |
| Gearbox |
SINOTRUK BRAND, manual operation, HW19710, 10 forward and 2 reverse, with Power Take-Off (PTO) |
| Front Axles |
HF9, 9000kg with drum brake system |
| Rear Axles |
HC16, 2X16000kg, double stage reduction (central+ hub), cast axle housing, ratio: 5.73 |
| Suspension | Front suspension: 10 pcs leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer |
| Rear suspension: 12 pcs leaf springs with bogie spring and stabilizer | |
| Steering System |
famous brand power steering, model ZF8118 , hydraulic steering with power assistance |
| Braking System |
Front drum rear drum brake, four-circuit protection valve Service brake: dual circuit compressed air brake Parking Brake(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake (optional): engine exhaust brake(EVB), antilock brake system (ABS), automatic brake gap adjustment arms |
| Tires |
12.00R20 (12.00-20, 315/80R22.5 optional), with one spare tyre |
| Fuel Tank Volume (L) |
300 |
| Dead Weight |
13110/8800 |
| Gross Vehicle Weight (kg) |
25000 |
| Overall Dimension (LxWxH) (mm) |
9000x2500x3945 |
| Wheelbase (mm) |
4000+1350 |
| Min.Ground Clearance (mm) |
314 |
| Approach/Depart Angle(°) | 16/ (26/35) |
| Gradeability (%) |
≥50 |
| Effective Mixing Volume(m³) |
10 |
| Remark (Engine Power Option) |
371HP |
