● Category:
● Brand Name: Wheel loader
● Dimension (mm): 7230*2520*3170
● Operating Weight (kg): 10700
● Origin: China
| Item | Specifications | Item | Specifications | Item | Specifications |
| Overall dimension | Operating weight | 10700kg | Speed at forward gear 1 | 0-38km/h | |
| L×W×H | 7100×2520×3170mm | Max.tractive force | ≥105kN | Speed at reverse gear 2 | 0-17km/h |
| Wheelbase | 2850mm | Max.breakout force | ≥96kN | Hydraulic system | |
| Min.ground clearance | 370mm | Tipping load | ≥66kN | Type | Hydraulic pilot control |
| Max.dumping height | 2950-3278mm | Engine | Total time | ≤9s | |
| Lifting height | 3789mm | Model | YC6J125Z-T20 | Brake system | |
| Dumping distance | 1020-1050mm | Type | Inline,Water-cooled,wet cylinder,direct injection | Service brake type | Air over hydraulic disc type |
| Max.gradeability | 30 | Rated power Speed | 92kw/2200r/min | Packing brake type | Electric air control disc brake |
| Dumping angle | 45 | Engine displacement | 6494mm | Steering system | |
| Bucket rollback at ground level | 45 | Cylinder bore/stroke | 105/125mm | Type | Load-sensing fully hydraulic articulated steering |
| Width of complete machine(outside of rear wheelM) | 2310mm | Max.torque | 500Nm | System pressure | 12MPa |
| Wheel tread | 1865mm | Emission standard | GB20891 II | Fill capacity | |
| Steering angle | 38 | Min.fuel-consume ratio | ≤235g/kw.h | Fuel | 140L |
| Horizontal crossing radius | 5912mm | Transmission system | Hydraulic oil | 128L | |
| Min.turing radius | 5381mm | Torque converter | Single-stage four-element double-turbine hydraulic torque converter | Engine | 17L |
| Overall parameters | Transmission type | planetary power shift | Transmission | 45L | |
| Bucket capacity | 1.6-1.8m3 | Gears | Forward 2 reverse 1 | Bridge | 2×18L |
| Rated load | 3000kg | Speed at forward gear 1 | 0-13km/h | Brake system | 4L |
