Type

Operating Weight(kg)

1293

Rated Load

345

Standard Bucket Capacity(m³)

0.18

Performance

Max. Working Speed(Km/h)

10.3

Max. Traction(KN)

9.5

Digging Force of Boom Cylinder(KN)

7.6

Digging Force of Bucket Cylinder(KN)

8.7

Engine

Brand

KUTOBA

Power(kw/rpm)

18.2/3000

Displacement(L)

1.123

Emission Standard

Euro 4

Dimensions

Overall Dimension(L*W*H)(mm)

1890*910*1810

Minimum Turning Radius(mm)

1460

Wheelbase(mm)

740

Wheel Track(mm)

762

Operating Range

Max. Operating Height(mm)

3051

Max. Dumping Height(mm)

1959

Dumping Distance

403
