Product classification
Product classification
● Category:
● Brand Name: Wheel loader
● Dimension (mm): 5095*1850*2557
● Operating Weight (kg): 3800
● Origin: China
| Performance | Rated loading (kg) | 1600 |
| Overall weight (kg) | 3800 | |
| Rated bucket capacity (m³) | 0.65 | |
| Maximum tractive force (kN) | 33 | |
| Maximum breakout force (kN) | 28 | |
| Maximum grade ability(°) | 20 | |
| Maximum dump height(mm) | 2394 | |
| Maximum dump reach(mm) | 1034 | |
| Overall dimension (L×W×H)(mm) |
5095*1850*2557mm | |
| Minimum turning radius (outside of wheels)(mm) |
5210 | |
| Maximum steering angle | 31° | |
| Oscillation angle | 8° | |
| Transmission system | Torque converter | 265 |
| Gearbox mode | Power shift normally engaged straight gear | |
| Gear shift | Electric, 2forward shift 2 reverse shift | |
| Maximum speed | 19km/h | |
| Drive axles | Main reducing mode | Bevel gear grade l reduction |
| Wheel base (mm) | 2282 | |
| Wheel tread(mm) | 1400 | |
| Ground clearance(mm) | 400 | |
| Hydraulic system | System working pressure (Mpa) | 18 |
| Boom lifting time (s) | 4 | |
| Total time (s) | 7 | |
| Fuel tank capacity (L) | 75 | |
| Function of leveling automatically | yes | |
| Brake system | Service brake | Air-assist hydraulic, disc brake |
| Parking brake | Manual disc brake | |
| Tyre | Type specification | 23.5/70-16 |
| Front tyre pressure (kPa) | 320 | |
| Rear tyre pressure (kPa) | 320 |
